China High Quality 240kw Natural Gas/Biogas/LPG Generator Set with ATS System

Product Description

With the decrease of coal energy and pollution, it is urgent to develop clean energy and improve energy efficiency. Weifang Huayuan has been to develop low energy consumption, pollution-free products as its mission, a new generation of gas turbine to clean natural gas and all kinds of biomass gas as fuel, turning waste into treasure, and recycling of resources.

Specification BIOgas generator ( 240KW )

Specification for BIOGAS GENERATOR
Type		HR-20GFQ	HR-25GFQ	HR-30GFQ
Phase and connection		3 phase 4 wire
Excitation		Brushless , AVR
Rated output (KW)		20	25	30
Current (A)		36	45	54
Voltage (V)		400
Frequency (HZ)		50
Power factor		0.8 (Lagging)
Voltage adjustion		AVR Automatic
Fuel type		Natural gas , Biogas
E N G I N E	Type	HR4100Q	HR4102Q	HR4105Q
	Model	In line , 4 stroke , water cooled , Electronic ignition
	Cylinder no. bore * stroke (MM)	4×100×115	4×102×115	4×105×115
	Displacement (L)	3.61	3.76	4.33
	Compression Ratio	11.3:1	11.4:1	11.5:1
	Rated output (KW)	25	30	38
	Rated speed (RPM)	1500
	Governing Method	Electronic governor
	Starting Method	Electric starting system
	(m³/kwh) Fuel Consumption	0.33 ( Natural Gas ) 0.64 ( Biogas )
Overall Size (LWH)(MM)		1650×720×1250	1650×740×1250	1650×740×1280
Weight		750	820	900
