5kw Horizontal Axis Wind Turbine System

Main technical parameter as follows:
1. Machine Type: horizontal-axis wind turbine
2. blade form: propeller
3. blade number: 3 pcs
4. balde material: glass fibre reinforced plastic
5. type of generator:permanent-magnet 3 phase AC
6. type of tower: guy wire or free standing
Power: 5KW
Blade diameter (m): 6.0
Rated Rotated speed (r/min): 200
Rated speed (m/s): 10
Rated power: 5KW
Max power: 7KW
Output voltage (v): 220
Start up wind speed (m/s): 3
Work speed (m/s): 3-30
Security wind speed(m/s):50
High of tower (m): 9
Top quality except tower: 285kg
Tower Steel tube model (mm):φ133
speed regulation: leaning tail + electric brake
Capacity and quantity of battery: 12V200AH18 pcs
Can supply power for:   Air conditioners, Refrigerators, Water pumps, Cookers, Color TV sets, Washing machines, Lighting, Electric fans, and Charge
