Yuchai 260kw 325kVA Generador Diesel PARA Salvador
1. GENERATOR DATA Voltage Available: 50Hz: 380-400-415V/220-230-240V;60Hz: 220-380-416-440-480V/110-208-220-240VAny special voltage is also available as client's requestPrime Power: Comply with GB/T2820-97(eqv.ISO8528). Genset can run unlimitedly under certain power......
Send Inquiry
Product Description
1. GENERATOR DATA
Voltage Available:
50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client's request
Prime Power:
Comply with GB/T2820-97(eqv.ISO8528).
Genset can run unlimitedly under certain power range.
One hour 10% over load in every 12 running hours is allowed;
Standby Power:
standby power is the limit value of maximum output for emergency use.
It is off-oil power,overloading is prohibited
2. MAIN SPECIFICATION
| Genset Model | KPYC330 | KPYC350 | KPYC385 | KPYC400 | |
| Rated Power | KW/KVA | 240/300 | 260/325 | 280/350 | 300/375 |
| Standby Power | KW/KVA | 264/330 | 280/350 | 308/385 | 320/400 |
| Rated Voltage | V | 220V/127V 380V/220V 400V/230V 415V/240V 480V/277V 600V/346V | |||
| Speed | RPM | 1500/1800 | |||
| Rated frequency | Hz | 50/60 | |||
| Engine Model | YC6MK390L-D20 | YC6MK420L-D20 | YC6MJ480L-D20 | YC6T550L-D21 | |
| Engine Power | KW | 286 | 309 | 352 | 405 |
| Air intake way | Turbo | Turbo | Turbo | Turbo | |
| Governor | Electronic | Electronic | Electronic | Electronic | |
| Cylinder | QTY | 6 | 6 | 6 | 6 |
| Bore*Stroke | mm*mm | 123×145 | 123×145 | 131×145 | 145×165 |
| Displacement | L | 10.338 | 10.338 | 11.726 | 16.35 |
| Fuel Consumption | g/kw.h | 195 | 195 | 195 | 195 |
| Compression Ratio | 17.5:1 | 17.5:1 | 17.5:1 | 15:1 | |
| Alternator Model | STF-314D | STF-314ES | STF-314E | STF-314FS | |
| Voltage Regulation | AVR | ||||
| Excitation Method | Brushless | ||||
| Open Type Size | mm | 3100x1200x1900 | 3100x1200x1900 | 3300x1300x1900 | 3400x1300x2000 |
| Open Type Weight | kg | 2480 | 2530 | 2680 | 3100 |
| Soundproof Size | mm | 3600x1300x2000 | 3600x1300x2000 | 3800x1400x2000 | 4000x1400x2100 |
| Soundproof Weight | kg | 3480 | 3560 | 3690 | 4260 |
3. PRODUCT FEATURES
(1).Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.
(8).50Hz and 60Hz both are available for choice
