Open and Silent Deutz Generator
Deutz engine. Cummins engine,Stable performance overload protectionRated power 20kw -500kw speed 1500rpm/1800rpmFrequency: 50hz/60hz rated voltage: 230v/400vRated current 14.4A-900AMotor: Brushless STAMFOR OR LEROY SUMMERColor: Yellow, orange green, whiteOutput type: AC THREE PHASEMODELGF2-20KW/25kv......
Send Inquiry
Product Description
Deutz engine. Cummins engine,Stable performance overload protection
Rated power 20kw -500kw speed 1500rpm/1800rpm
Frequency: 50hz/60hz rated voltage: 230v/400v
Rated current 14.4A-900A
Motor: Brushless STAMFOR OR LEROY SUMMER
Color: Yellow, orange green, white
Output type: AC THREE PHASE
| MODEL | GF2-20KW/25kva |
| Powered by Deutz Engine | |
| Continuous Power (50HZ) | 20KW/25KVA |
| Standby Power (50HZ) | 22KW/27.5KVA |
| Engine Model | D226B – 3D |
| Engine Power (50HZ) | 31KW |
| Engine Manufacturer | Sino-Germany joint venture Weichai – Deutz Co., Ltd |
| Speed | 1500rpm |
| Fuel Consumption | ≤ 215 g/kw. h |
| Lubricating Oil Consumption | ≤ 1.36 g/kw. h |
| 100% Load Fuel Consumption | 6.5 Lwhen continuous power |
| 7.1 Lwhen standby power | |
| Cooling Method | Water - cooled |
| Starting Method | 24V DC electrical start |
| Engine Total Dispalecment | 3.12 L |
| Compress Ratio | 16.5: 1 |
| Bore X Stroke | 105 x 120 mm |
| Alternator Model | Stamford copy 184F |
| Alternator Power | 22KW/27.5KVA |
| Voltage | 380/220V |
| Electric Current | 36A |
| Power Factor | 0.8 |
| Phase | 3-phases |
| Brush/Brushless | Brushless |
| Insulation Class/Protection Grade | H Class/IP23 |
| G. W | 615 KGS |
| Overall Size | 2100x960x1174 MM |
| 20FT | 6 PCS |
| OPTIONAL | ATS(AUTO TRANFORE SWITCH) |
| Auto Battery Charger | |
| Base fuel tank (for open type) | |
