Mitsubishi Engine 73kw to 1080kw Diesel Generator Set
1. GENERATOR DATA Voltage Available: 50Hz: 380-400-415V/220-230-240V;60Hz: 220-380-416-440-480V/110-208-220-240VAny special voltage is also available as client's requestPrime Power: Comply with GB/T2820-97(eqv.ISO8528). Genset can run unlimitedly under certain power......
Send Inquiry
Product Description
1. GENERATOR DATA
Voltage Available:
50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client's request
Prime Power:
Comply with GB/T2820-97(eqv.ISO8528).
Genset can run unlimitedly under certain power range.
One hour 10% over load in every 12 running hours is allowed;
Standby Power:
standby power is the limit value of maximum output for emergency use.
It is off-oil power,overloading is prohibited
2. MAIN SPECIFICATION
| Genset Model | KPM100 | KPM725 | KPM825 | KPM1375 | KPM1500 | |
| Rated Power | KW/KVA | 73/91 | 536/670 | 600/750 | 1000/1250 | 1080/1350 |
| Standby Power | KW/KVA | 80/100 | 580/725 | 660/825 | 1100/1375 | 1200/1500 |
| Rated Voltage | V | 220V/127V 380V/220V 400V/230V 415V/240V 480V/277V 600V/346V | ||||
| Speed | RPM | 1500/1800 | ||||
| Rated frequency | Hz | 50/60 | ||||
| Engine Model | S6K-DT | S6R2-PTA | S6R2-PTAA | S12R-PTA | S12R-PTA2 | |
| Engine Power | KW | 89.7 | 635 | 710 | 1220 | 1315 |
| Air intake way | Turbo | Turbo | Turbo | Turbo | Turbo | |
| Governor | Electronic | Electronic | Electronic | Electronic | Electronic | |
| Cylinder | QTY | 6 | 6 | 6 | 12 | 12 |
| Bore*Stroke | mm*mm | 1302×130 | 170×220 | 170×220 | 170×180 | 170×180 |
| Displacement | L | 6.373 | 29.96 | 29.96 | 49.03 | 49.03 |
| Fuel Consumption | g/kw.h | 245 | 235 | 235 | 235 | 235 |
| Compression Ratio | 17:1 | 14.1:1 | 14.1:1 | 14:1 | 13.5:1 | |
| Alternator Model | STF-274C | STF-354F | STF-634B | STF-634G | STF-734B | |
| Voltage Regulation | AVR | |||||
| Excitation Method | Brushless | |||||
| Open Type Size | mm | 2400x800x1300 | 4200x1400x1800 | 4200x1400x1800 | 4800x1800x2200 | 4800x1800x2200 |
| Open Type Weight | kg | 1380 | 3600 | 4260 | 7800 | 8200 |
| Soundproof Size | mm | 2800x1050x1400 | 5000x1600x2000 | 5000x1600x2000 | 5800x1900x2250 | 5800x1900x2250 |
| Soundproof Weight | kg | 1960 | 5260 | 5900 | 9860 | 10800 |
3. PRODUCT FEATURES
(1).Full control panel with power indicator light and oil light.
(2).Emergency shutdown for low oil pressure and high water temperature.
(3).Large fuel tank ensure continuous running.
(4).Low noise & vibration.
(5).Compact structure.
(6).Reliable performance.
(7).Easy for installation and maintenance.
(8).50Hz and 60Hz both are available for choice
