Diesel Soundproof Generators (GF2-75KW) , Super Silent
Big power diesel generator set: Soundproof encolsure, elegant appearance, reduce noise level effectively. Output from 10KVA to 150KVA for wei chai engine.MODELGF2- 75KWPowered by Weichai EngineContinuous Power (50HZ/60HZ)75KW/94KVAStandby Power (50HZ/60HZ)82KW/102.5KVAEngine Model6105ZDEngine Powe......
Send Inquiry
Product Description
Big power diesel generator set: Soundproof encolsure, elegant appearance, reduce noise level effectively. Output from 10KVA to 150KVA for wei chai engine.| MODEL | GF2- 75KW |
| Powered by Weichai Engine | |
| Continuous Power (50HZ/60HZ) | 75KW/94KVA |
| Standby Power (50HZ/60HZ) | 82KW/102.5KVA |
| Engine Model | 6105ZD |
| Engine Power (50HZ) | 84KW/105KVA |
| Engine Max Power(50HZ) | 92.4KW/115.5KVA |
| Speed | 1500rpm/1800rpm |
| Fuel Consumption | 224 g/kw. h |
| Cooling Method | Water - cooled |
| Starting Method | 24V DC electrical start |
| Alternator Model | TFW-75 |
| Alternator Power | 75KW/94KVA |
| Voltage | 380/220V |
| Electric Current | 135A |
| Power Factor | 0.8 |
| Phase | 3-phases |
| Brush/Brushless | Brushless |
| G. W/N. W | 1900/1820 KGS |
| Overall Size | 2820x1230x1660 MM |
| 20FT | 4 PCS |
| OPTIONAL | |
| Panel | Auto Transfer Switch (ATS) Control Panel |
| ATS | Electricity Output Cabinet (≥ 75KW better chose) |
