Biogas Generator 20kw 25kVA Factory Price Gas Generator
Product DescriptionNatural Gas,Biogas ,Landfill Gas,Oil Field Gas generator set. Safety - Stability - Economy - Reliability Power1. Brand new original Natural Gas / Biogas special use water cooled diesel engine2. Engine ECU governing and ignition system use BOSH and Germany part, with High reliabili......
Send Inquiry
Product Description
Natural Gas,Biogas ,Landfill Gas,Oil Field Gas generator set. Safety - Stability - Economy - Reliability Power
1. Brand new original Natural Gas / Biogas special use water cooled diesel engine
2. Engine ECU governing and ignition system use BOSH and Germany part, with High reliability and safety
3. Genset equipped with explosion-proof safety system and Gas mixture automatically control system
4. Brand new Stamford type brushless AC alternator, 230/400V, 3-Phase, 50Hz,60hz, 1500Rpm/1800rpm, 0.8PF, IP23, H insulation class
5. Genset equipped with radiator with engine driven fan mounted on skid.
6. Genset Digital-6120U Automatic control system of diesel generator include, High speed protect, High water temperature protect, low oil pressure protect, 3 phase Voltage,current and frequency,calculagraph,output power, LED display with AMF functions (for ATS)
7. Genset equipped with MCCB
8. Anti-vibration mounting
9. 24V DC Electric start system with maintenance free battery and Battery Connect wire
10. ndustrial class silencers with flexible connects and elbow
11. Genset with engine manual, controller manual, operation manual and standard engine tools
12. H igh protect class control box and power output box. IP55, Waterproof, Electric leakage protect, Breaker
Natural Gas,Biogas ,Landfill Gas,Oil Field Gas,Wood gas ,methane gas, LPG, generator set.
Gas generator set image
Natural Gas,Biogas ,Landfill Gas,Oil Field Gas generator set.
| Main standards | GB/T2820, ISO8528,IEC34, CE, EPA Tier4 standard |
| Prime output power | from 5KVA to 2500KVA |
| Rated voltage | 120V/240V, 220/380V, 230V/400V, 254V/440V etc. other voltage is optional |
| Generator phase and connecting | 3 phase, 4wire |
| Rated frequency | 50Hz@1500rpm or 60Hz@1800rpm |
| Alternator excited type | Brushless, self excited or PMG optional |
| Alternator Insulation | Class H |
| Alternator Protection | IP21 ~ IP23 |
| Voltage regulation | AVR automatic control 1% |
| Altitude above sea level | ≤1000 meters |
| Ambient air temperature | ≤40°C |
| Relative air humidity | ≤ 90% |
Certification
Our Company
Product Warranty Details
1.JET product has guarantee for one year or 1000 hours whichever reach first from ex-factory date.
2. During the guarantee period, our will provide the free easy-damageable spare parts of alternator caused by our quality of production or raw material.
3.After expiration, our provides cost spare parts maintenance of alternator. If engine with international warranty service, the engine product warranty by local authorization Service agent.
