Home > Products > Diesel Generator > 50Hz Diesel Generator Set R-C Series R- DC220 -S 220kVA / 176kw Soundproof Sets
50Hz Diesel Generator Set R-C Series R- DC220 -S 220kVA / 176kw Soundproof Sets
50HZ Diesel Generator Set R-C Series R-DC220-S 220kVA / 176kW Soundproof SetsA diesel generator is the combination of a diesel engine with an electric generator to generate electrical energy. This is a specific case of engine-generator. A diesel compression-ignition engine is usually designed to run......
Send Inquiry
Product Description
50HZ Diesel Generator Set R-C Series R-DC220-S 220kVA / 176kW Soundproof Sets
A diesel generator is the combination of a diesel engine with an electric generator to generate electrical energy. This is a specific case of engine-generator. A diesel compression-ignition engine is usually designed to run on diesel fuel, but some types are adapted for other liquid fuels or natural gas.
Features
Contacts
If you have any questions, please feel free to contact me.
All the information and pictures above are subject to change without further notice.
All rights reserved@ CESE2
A diesel generator is the combination of a diesel engine with an electric generator to generate electrical energy. This is a specific case of engine-generator. A diesel compression-ignition engine is usually designed to run on diesel fuel, but some types are adapted for other liquid fuels or natural gas.
Features
- Strong power, high torque, easy to maintain, easy to start;
- Low noise, low emissions;
- Cabinet made of high quality sheet metal, corrosion-resistant, scratch-resistant;
- Canopy sealing performance, high waterproof, dust-proof, rain, dust and other difficult to access;
- Omni-directional control, easy connection and simple;
- Cranes, fork, pull, drag, easy transportation;
- ≥8-hour fuel tanks;
- Open Type with 40 c radiator, Soundproof type with 50 ºCradiator
No. of Cylinders / Alignment 6 / In Line Gross Engine Power(kW) Prime 183 Cycle 4 Stroke Standby 203 Bore / Stroke 114 mm / 135 mm Compression Ratio 18:1 Induction TCADisplacement (L) 8.3 Cooling Method Water Governing Type Electronic Lubricant Oil 15W40-CF4 Upgrade Net weight (kg) 684 Lubricant Oil Capacity(L) 23.8 Coolant Capacity(L) 12.3 Rated Capacity(kVA) 200 A.V.R. Model AS440 Rated Power(kW) 160 Voltage Regulation (no load- full load) ± 1.0% THF(BS EN60034 - 1) <2% Underspeed Protection Standard Bearing Number Single Protection IP23 Windings 100% Copper Phase Sequence A(U), B(V), C(W) Silicon Steel Core Processing One Piece Punching TIF(NEMA MG 1-22) <50 Insulation Class H Excitation System Self-excited, SHUNT Winding Pitch 2 / 3 Ambient Temp 50 ºC Amortisseur Winding Full Stator Rated Temp 125 ºC
