3kw Portable Open Frame Diesel Generator (KDE3500E)
Frequency (Hz): 50 60Output power (kVA): 2.8; 3Max. Power(kVA): 3; 3.2Voltage (V): 115/230; 120/240Current &......
Send Inquiry
Product Description
Frequency (Hz): 50 60
Output power (kVA): 2.8; 3
Max. Power(kVA): 3; 3.2
Voltage (V): 115/230; 120/240
Current (A): 24.4/12.2; 25/12.5
Engine speed (r/min): 3000; 3600
Excitation system: (AVR) self-excited constant voltage
Noise level (7m) dB (A): 77
Fuel tank capacity (L): 12.5
Structure: Open-frame
Panel: Ordinary
Output socket: Two
Output terminal post: No
DC12V output: Terminal post
Net weight (kg): E: 70
Dimension (L*W*H)(mm): 680 *530*590
Engine model: KA178F
Engine type: Single-cylinder, vertical, air-cooled, direct injection
Bore*stroke (mm): 78 *62
Displacement (L): 0.296
Power (KW): 3.68/3000 4/3600
Fuel consumption rate (g. KW/h): 276.1 285.6
Compression ratio: 20
Lubrication system: Spring
Engine starting system:
Type E: Electric starter
Diesel oil model: Summer: 0#, winter: -10#
Lube oil model: SAE10W-30 (above CD grade)
Lube oil capacity (L): 1.1
Battery capacity(V-AH): 12V-36Ah
Output power (kVA): 2.8; 3
Max. Power(kVA): 3; 3.2
Voltage (V): 115/230; 120/240
Current (A): 24.4/12.2; 25/12.5
Engine speed (r/min): 3000; 3600
Excitation system: (AVR) self-excited constant voltage
Noise level (7m) dB (A): 77
Fuel tank capacity (L): 12.5
Structure: Open-frame
Panel: Ordinary
Output socket: Two
Output terminal post: No
DC12V output: Terminal post
Net weight (kg): E: 70
Dimension (L*W*H)(mm): 680 *530*590
Engine model: KA178F
Engine type: Single-cylinder, vertical, air-cooled, direct injection
Bore*stroke (mm): 78 *62
Displacement (L): 0.296
Power (KW): 3.68/3000 4/3600
Fuel consumption rate (g. KW/h): 276.1 285.6
Compression ratio: 20
Lubrication system: Spring
Engine starting system:
Type E: Electric starter
Diesel oil model: Summer: 0#, winter: -10#
Lube oil model: SAE10W-30 (above CD grade)
Lube oil capacity (L): 1.1
Battery capacity(V-AH): 12V-36Ah
| Frequency (HZ): 50 60 |
| Output power (KVA): 2.8 3 |
| Max. power(KVA):3 3.2 |
| Voltage (V):115/230 120/240 |
| Current (A): 24.4/12.2 25/12.5 |
| Engine speed (r/min): 3000 3600 |
| Phase: single |
| Power factor: 1 |
| Excitation system: (AVR) self-excited constant voltage |
| Noise level (7m) dB (A): X/E:77 T:72 |
| Fuel tank capacity (L): X/E: 12.5 T:15 |
| Structure : X/E:open-frame T:silent |
| Panel :ordinary |
| Output socket: two |
| Output terminal post: No |
| DC12V output: terminal post |
| Net weight (kg): X:53 E:70 T:140 |
| Dimension (L*W*H)(mm): X/E :680 *530*590 T:830*532*740 |
| Engine model: KA178F |
| Engine type: Single-cylinder, vertical, air-cooled, direct injection |
| Bore*stroke (mm): 78 *62 |
| Displacement (L): 0.296 |
| Power (KW): 3.68/3000 4/3600 |
| Fuel consumption rate (g. KW/h): 276.1 285.6 |
| Compression ratio: 20 |
| Lubrication system: Spring |
| Engine starting system: type X: Recoil starter |
| type E: Electric starter |
| Diesel oil model: Summer: 0#, winter: -10# |
| Lube oil model: SAE10W-30 (above CD grade) |
| Lube oil capacity (L): 1.1 |
| Battery capacity(V-AH): 12V-36Ah |
