2500kVA Output Power Yuchai Diesel Generator YC2500G Power Generator

Yuchai Diesel Engine is made by Germany equipment, MTU technology
With integral cast iron crankshaft, alloy cast iron cylinder number head, the engine has the advantages of compact size, ligh weight, less vibration, low noise and high reliability.
4-Valve with electronics unit pump (EUP) injection system and advanced injector provide better combustion, lower fuel consumption.
Dual thermostats with gear driven water pump improve reliability and cooling efficiency.
User friendly with low emissions.
More power reserve, better performance.
Good parts commonality.

Alternator: Leroy Somer, Marathon, MECC brand, AC, self-excited, AVR, H/23,
Controller: Deepsea, ComAp, Smartgen


Genset model:    YC2500G
Standby power:   2500KVA/2000KW
Prime power:     2300KVA/1840KW
Continuous duty 24/24H under variable load -10% overcharge acceptable
Prime power:    12 hours per day
Standby power:  duty-operation under variable charge 500h/year without overcharge-for continuous use.

Engine model:   YC16VC2960L-D30
Configuration:    Vertical, V-configuration, Water cooled, 4-stroke
Aspiration:       Turbocharged & intercooled
Cylinder:         16 cylinder Vee type
Bore* Stroke:     200*210mm
Displacement:     105.56L
Compression ratio:  13.5 : 1
Rated power:      1980KW
Max power:        2178KW
Fuel consumption:  195g/kw.h
Oil capacity:        370L
Oil consumption:     1g/kw.h
Altitude without derating:  less than 2500m
