Water Turbine
Features:1.suitable for high head,small flow and flow changes in large runoff hydropower station.2.With the power plant investment is small,compact units structure characteristics.3.Has the efficiency changes smoothly,operating a wide range,even in the 15--20% load is reduced efficiency.4.Suitable f......
Send Inquiry
Product Description
Features:
1.suitable for high head,small flow and flow changes in large runoff hydropower station.
2.With the power plant investment is small,compact units structure characteristics.
3.Has the efficiency changes smoothly,operating a wide range,even in the 15--20% load is reduced efficiency.
4.Suitable for high head,small flow station in mountainous area.
5.A unit construction,simple restrictions without cavitation condition,the advantages of stable operation,less investment,construction area.
Parameter for water turbine:
Model:XJA-W-35/1÷6.
Designed water head:80meters.
Water flow:0.14M3/S.
Power:75KW.
Designed speed:1000r/min.
Parameter for generator:
Model:SFW75-6/3 68.
Power:75KW.
Rated voltage:400V.
Rated current:135A.
Rated speed:1000r/min.
Inlet valve:200mm.
1.suitable for high head,small flow and flow changes in large runoff hydropower station.
2.With the power plant investment is small,compact units structure characteristics.
3.Has the efficiency changes smoothly,operating a wide range,even in the 15--20% load is reduced efficiency.
4.Suitable for high head,small flow station in mountainous area.
5.A unit construction,simple restrictions without cavitation condition,the advantages of stable operation,less investment,construction area.
Parameter for water turbine:
Model:XJA-W-35/1÷6.
Designed water head:80meters.
Water flow:0.14M3/S.
Power:75KW.
Designed speed:1000r/min.
Parameter for generator:
Model:SFW75-6/3 68.
Power:75KW.
Rated voltage:400V.
Rated current:135A.
Rated speed:1000r/min.
Inlet valve:200mm.
