New 2, 000 Watt 5.5HP Ohv 4-Cycle Gasoline Powered Portable Generator
C.A.G TS series Gasoline Portable Generators TS2500 are powered by a reliable single cylinder, OHV air cooled 4-cycle, 5.5HP petrol engine. The OHV engine is equipped with a low oil shutdown system that protects the engine from costly damage. This unit has a square tube design, with dual folding han......
Send Inquiry
Product Description
C.A.G TS series Gasoline Portable Generators TS2500 are powered by a reliable single cylinder, OHV air cooled 4-cycle, 5.5HP petrol engine. The OHV engine is equipped with a low oil shutdown system that protects the engine from costly damage. This unit has a square tube design, with dual folding handles and 8-inch never-flat wheels for balanced carrying. This gasoline portable generator provides reliable, clean, and instant power, and is ideal for emergencies, job site use, recreation, household, lawn and garden, operating small tools, and serving as home back-up power.
Small Gasoline Generator
| Data for CAG Gasoline Generator | |
Model | TS2500 |
| Type | Brush |
| Voltage Regulate | AVR |
| Frequency Hz | 50 | 60 |
| Rated AC Voltage (V) | 230V | 120V-240V |
| Rated AC Output (KVA) | 2.0 | 2.5 |
| Peak AC Output (KVA) | 2.2 | 2.8 |
| Power Factor COSφ | 1 |
| Model | TE160 |
| Type | OHV,4-stroke, single cylinder,Air-cooled |
| Bore x Stroke (mm) | 68×45 |
| Displacement (ml) | 163 |
| Max. output (HP/rpm) | 5.5/3600 |
| Fuel Type | Unleaded Gasoline |
| Fuel Tank Capacity (L) | 15L |
| Continuous Operating 1/2 load (h) | 13 |
| Engine Oil Standard | SF or Higher Grade |
| Oil Capacity (L/gal) | 0.6/0.16 |
| Ignition system | T.C.I. |
| Starting System | Recoil and hand-operated /Electric start |
| Operating Noise Level (7m) dB(A) | 67 |
| Dimensions L×W×H (mm) | 610x460x470 |
| Net /Gross Weight (kg) | 38/40 |
| 20/40FT unit | 225 / 475 |
• Equipped with excellent CAG gasoline engine
• 10% more efficiency,less noise and better emission
• User-friendly professional control panel
• Optional low-oil shutdown protects the generator
• Full tubular-frame protection with vibration-damping mounts
• Optional wheel-kit for easy transport
• Optional AVR and ATS available
• EU, US , AU and other receptacle for choice.
• Self-start and remoter start as an optional.
• Optional Copper/ Aluminium Alternator
• Optional Single-Phase or three phase
• Optional EMC,DC,Digital display counter
